1.Environmental friendliness:
Carbon dioxide, as a natural refrigerant, has an ozone depletion potential (ODP) of 0 and a global warming potential (GWP) of only 1, which is much lower than traditional refrigerants (such as R410A with a GWP of 2080). It is environmentally friendly and meets global carbon neutrality goals.
2.Efficient and energy-saving:
The carbon dioxide heat pump adopts transcritical cycle technology, with high heating efficiency and a COP (energy efficiency ratio) of over 4.0. The heating efficiency attenuation is small in low-temperature environments, and the energy-saving effect is significant. Compared with heating equipment such as oil boilers, gas boilers, and electric boilers, the energy-saving rate is over 50%.
3.High temperature heating:
Carbon dioxide heat pumps can stably supply hot water at temperatures above 90 ℃, meeting the high temperature needs of industries such as food processing and electroplating. Meanwhile, its heating end can adopt various forms such as radiators, floor radiant heating, or fan coil units.
4.Stable low-temperature operation:
The carbon dioxide heat pump can start and operate at a low temperature of -45 ℃, and can still produce high-temperature hot water at an ambient temperature of -35 ℃. It is suitable for heating and domestic hot water supply in cold regions.
| Unit type | SJKRS-28 II/C | SJKRS-36II/C | SJKRS-55 II/C | SJKRS-73 I/C | SJKRS-106 IC | SJKRS-I60II /C | |
| Specifications | 7.5HP | 10HP | 15HP | 20HP | 30HP | 40HP | |
| Power supply | Three-phase five-vire380V/50Hz | ||||||
| Heating mode | Direct heat/cycle type | ||||||
| Standard working condition | Heating capacity(kw) | 27.5 | 36.7 | 55.1 | 72.8 | 10.6.5 | 155.1 |
| Input Power(kw) | 6.1 | 8.2 | 13.7 | 16.1 | 23.6 | 34.5 | |
| COP | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | |
| Hot Water flow(m³/h) | 0.59 | 0.79 | 1.18 | 1.56 | 2.29 | 3.33 | |
| High temperature condition | Heating capacity kw) | 23.9 | 28.5 | 51.5 | 59.5 | 89 | 13.1.5 |
| Input Power(kw) | 7.5 | 8.9 | 16.1 | 18.6 | 27.8 | 41.1 | |
| COP | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | |
| Hot Water flow(m³/h) | 0.27 | 0.33 | 0.59 | 0.68 | 1.02 | 1.51 | |
| Low temperature condition | Heating capacity(kw) | 17.3 | 21.4 | 34.8 | 41.5 | 62.2 | 94.5 |
| Input Power(kw) | 6.2 | 7.6 | 12.4 | 14.8 | 22.2 | 33.8 | |
| COP | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | |
| Hot Water flow(m³/h) | 0.32 | 0.4 | 0.65 | 0.78 | 1.16 | 1.77 | |
| Component Information | Size of water pipe joint | DN20 | DN25 | DN32 | DN40 | ||
| Water heat exchanger | Plate or sleeve heat exchanger | ||||||
| Air Heat Exchanger | Aluminum Fin for copper tube | ||||||
| compressor type | Semi-closed reciprocating | ||||||
| Operation Panel | Color touch screen | ||||||
| Maximum outlet tenperature(℃) | 90℃ | ||||||
| Refrigerants | R744(C02) | ||||||
| Design pressure(MPa) | High side 15,low side 8 | ||||||
| Dimensions(length,width and height mm) | 1450x950x1450 | 1600x950x1500 | 1850x1150x1900 | 2050x1150x1950 | 2670x1410x2150 | 2290x2270x1980 | |
| Noise(dB) | 56 | 59 | 62 | 67 | 70 | 70 | |
| Weight(kg) | 550 | 660 | 780 | 860 | 1180 | 221360 | |
| SCOPE of use | Feed water temperature(℃) | 5~40 | |||||
| Feed vater pressure | 0.05~0.4 | ||||||
| Effluent temperature(℃) | 55~90 | ||||||
| Maximun flow | 1.2 | 1.5 | 2.4 | 3.2 | 4.9 | 6.5 | |
| Ambient temperature(℃) | -20~43 | ||||||
| Note: | 1)standard working conditions:ambient temperature DB 20°c/WB 15°C,using side initial water temperature 15°C,termination vater temperature 55°c; | ||||||
| 2)high temperature effluent:Ambient Temperature DB 20°c/WB 15°c,using side initial water temperature 15°C,termination water temperature 90°c; | |||||||
| 3)low temperature working condition:ambient temperature DB-10°C,using side initial water temperature 9°C,termination vater temperature 55°c. | |||||||
Industrial waste heat recovery and process heating:
Carbon dioxide heat pumps can be used for waste heat recovery, process heating, and steam production in industries such as petrochemicals, food processing, and pharmaceuticals.
In the agricultural field, carbon dioxide heat pumps can be used for greenhouse heating, drying of agricultural products, etc. By providing a stable temperature and humidity environment, crop growth is promoted, and agricultural product yield and quality are improved.
Regional heating and comprehensive energy utilization: Carbon dioxide heat pumps can be used in urban centralized heating, energy stations, comprehensive energy services, and other fields.
>> Product Operate Guide
After receiving the goods, the buyer will provide a instructional video.
Q1.What is the performance coefficient (COP) of a carbon dioxide (CO₂) heat pump?
A: Under standard operating conditions (7 °C ambient temperature and 55 °C outlet water temperature), the COP of a CO₂ heat pump can exceed 4.0. This implies that the system can generate 4 kWh of thermal energy per 1 kWh of electrical energy consumed, demonstrating a substantially higher efficiency compared to electric boilers (COP ≈ 1) and gas boilers (COP ≈ 0.9).
Q2.Does the CO₂ heat pump maintain reliable performance under winter low-temperature conditions?
A: Yes. CO₂ heat pumps are engineered for low-temperature adaptability and can achieve stable operation even at extreme cold temperatures as low as −35 °C. Their heat dissipation is minimized, and the heating efficiency (COP) remains significantly superior to that of conventional heat pumps, rendering them particularly well-suited for regions with harsh winter climates.
