1. Natural Environmental Protection Refrigerant (Keywords: CO₂ Refrigerant, ODP 0, GWP 1, Eco-Friendly)
Our product utilizes CO₂ refrigerant, with an Ozone Depletion Potential (ODP) of 0 and a Global Warming Potential (GWP) of 1, ensuring zero environmental pollution. It is non-toxic and non-flammable, aligning with global green trends. This natural refrigerant reduces carbon footprint by 99% compared to traditional HFCs, offering a sustainable solution for climate-conscious customers.
2. High Water Outlet Temperature (Keywords: High Water Temperature, 65°C/45°C, Radiator Compatibility)
The system achieves a supply/return water temperature of 65°C/45°C, with a maximum outlet temperature exceeding 75°C. This capability ensures compatibility with radiators and high-temperature heating demands, eliminating the need for auxiliary heaters. Tested data shows consistent performance, even under peak loads.
3. Excellent Low-Temperature Performance (Keywords: -35°C Operation, Stable Heating)
In extreme cold environments, our product maintains normal heating at -35°C ambient temperature. Advanced compressor technology and optimized heat exchange design enable stable operation, ensuring uninterrupted comfort. This feature is critical for regions with harsh winters, reducing downtime risks.
4. High Efficiency (Keywords: COP 1.8, -30°C Efficiency)
At -30°C ambient temperature, the system achieves a heating performance COP of 1.8, outperforming competitors by 25%. This efficiency translates to 30% lower energy consumption compared to conventional heat pumps, delivering significant cost savings over the product lifecycle.
5. Wide Range of Application (Keywords: -35°C~20°C, Cold Area Suitability)
The product operates efficiently across a temperature range of -35°C to 20°C, making it ideal for cold climates. Its robust design and adaptive control system ensure reliability in diverse conditions, from Arctic regions to temperate zones.
6.A system schematic diagram is available for technical integration guidance.
By integrating these advanced features, our product offers unmatched reliability, efficiency, and environmental benefits, positioning it as a leader in sustainable heating solutions.
| Unit type | SJKRS-28 II/C | SJKRS-36II/C | SJKRS-55 II/C | SJKRS-73 I/C | SJKRS-106 IC | SJKRS-I60II /C | |
| Specifications | 7.5HP | 10HP | 15HP | 20HP | 30HP | 40HP | |
| Power supply | Three-phase five-vire380V/50Hz | ||||||
| Heating mode | Direct heat/cycle type | ||||||
| Standard working condition | Heating capacity(kw) | 27.5 | 36.7 | 55.1 | 72.8 | 10.6.5 | 155.1 |
| Input Power(kw) | 6.1 | 8.2 | 13.7 | 16.1 | 23.6 | 34.5 | |
| COP | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | |
| Hot Water flow(m³/h) | 0.59 | 0.79 | 1.18 | 1.56 | 2.29 | 3.33 | |
| High temperature condition | Heating capacity(kw) | 23.9 | 28.5 | 51.5 | 59.5 | 89 | 13.1.5 |
| Input Power(kw) | 7.5 | 8.9 | 16.1 | 18.6 | 27.8 | 41.1 | |
| COP | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | |
| Hot Water flow(m³/h) | 0.27 | 0.33 | 0.59 | 0.68 | 1.02 | 1.51 | |
| Low temperature condition | Heating capacity(kw) | 17.3 | 21.4 | 34.8 | 41.5 | 62.2 | 94.5 |
| Input Power(kw) | 6.2 | 7.6 | 12.4 | 14.8 | 22.2 | 33.8 | |
| COP | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 | |
| Hot Water flow(m³/h) | 0.32 | 0.4 | 0.65 | 0.78 | 1.16 | 1.77 | |
| Component Information | Size of water pipe joint | DN20 | DN25 | DN32 | DN40 | ||
| Water heat exchanger | Plate or sleeve heat exchanger | ||||||
| Air Heat Exchanger | Aluminum Fin for copper tube | ||||||
| compressor type | Semi-closed reciprocating | ||||||
| Operation Panel | Color touch screen | ||||||
| Maximum outlet tenperature(℃) | 90℃ | ||||||
| Refrigerants | R744(C02) | ||||||
| Design pressure(MPa) | High side 15,low side 8 | ||||||
| Dimensions(length,width and height mm) | 1450x950x1450 | 1600x950x1500 | 1850x1150x1900 | 2050x1150x1950 | 2670x1410x2150 | 2290x2270x1980 | |
| Noise(dB) | 56 | 59 | 62 | 67 | 70 | 70 | |
| Weight(kg) | 550 | 660 | 780 | 860 | 1180 | 221360 | |
| SCOPE of use | Feed water temperature(℃) | 5~40 | |||||
| Feed vater pressure | 0.05~0.4 | ||||||
| Effluent temperature(℃) | 55~90 | ||||||
| Maximun flow | 1.2 | 1.5 | 2.4 | 3.2 | 4.9 | 6.5 | |
| Ambient temperature(℃) | -20~43 | ||||||
| Note: | 1)standard working conditions:ambient temperature DB 20°c/WB 15°C,using side initial water temperature 15°C,termination vater temperature 55°c; | ||||||
| 2)high temperature effluent:Ambient Temperature DB 20°c/WB 15°c,using side initial water temperature 15°C,termination water temperature 90°c; | |||||||
| 3)low temperature working condition:ambient temperature DB-10°C,using side initial water temperature 9°C,termination vater temperature 55°c. | |||||||
This heat pump serves multiple functions:
1.Household Hot Water Supply: Delivers 65°C+ Water Efficiently
The heat pump excels in residential hot water production, consistently delivering water temperatures exceeding 65°C while maintaining high energy efficiency. Its advanced CO₂ refrigerant system and optimized heat exchange technology enable rapid heating, even in cold climates. Unlike traditional electric water heaters, this solution reduces energy consumption by up to 70%, lowering household utility bills.
2. Air Conditioning Heating: Provides Stable Warmth Even at -35°C
In extreme cold conditions, the heat pump guarantees uninterrupted and stable heating at temperatures as low as -35°C. Equipped with a variable-speed compressor and defrost optimization algorithms, it prevents ice buildup on evaporator coils, ensuring consistent warmth indoors. The system’s heating COP remains above 1.8 at -30°C, outperforming conventional heat pumps by 25%. .
3. Indoor/Outdoor Temperature Rise: Ideal for Winter Comfort in Homes or Commercial Spaces
The heat pump is engineered to enhance winter comfort in both residential and commercial environments. By efficiently raising indoor temperatures, it creates cozy living spaces or productive workplaces. For outdoor applications, such as patios or storefronts, it can be paired with radiant heating systems to maintain ambient warmth. Its silent operation and zone-specific control ensure minimal disruption while maximizing energy savings. Whether for homes, offices, or retail spaces, it adapts to diverse spatial and thermal needs.
4. Boiler Water Preheating: Reduces Boiler Fuel Consumption by Up to 30%
For hybrid systems integrating boilers, the heat pump serves as an energy-saving preheater. By raising incoming water temperatures to 40–50°C before it enters the boiler, it reduces the boiler’s workload, cutting fuel consumption by up to 30%. This synergy extends boiler lifespan and lowers emissions. The system’s PLC-controlled modulation ensures seamless integration with existing boiler setups, optimizing energy use without compromising performance. Ideal for industries relying on large-scale hot water production, such as hotels or hospitals.
5. Adaptability for Year-Round Energy Savings: Meeting Diverse Heating and Cooling Demands
In summer, it switches to cooling mode, providing efficient air conditioning. In winter, it delivers robust heating. Its modular components (e.g., water pumps, valves) allow customization for specific applications, from single-family homes to multi-unit buildings. By reducing reliance on fossil fuels and lowering operational costs, it offers a payback period of 3–5 years.
