90℃ High Temperature Air Source Heat Pump FKH-100IICGW

Air source high-temperature heat pump is a device that uses air as a heat source, converts low-grade thermal energy in the air into high-grade thermal energy through heat pump technology, and can provide high-temperature hot water up to 90 ℃. It adopts advanced technologies such as two-stage compression and intermediate heat exchange, achieving the function of efficiently and stably providing high-temperature hot water in low-temperature environments.

Quantity:
Availability:





Inquire Add to Basket

>> Product Advantage

Heat pumps have the ability to integrate with various renewable energy sources, including solar and geothermal energy, to establish a multi energy complementary heating framework. This integration helps to improve the stability and reliability of the heating process.

1.Custom temperature configuration:

Users can flexibly personalize their heating experience by setting different temperature levels for different time intervals. This can be achieved through mobile applications or control panels based on their specific requirements and preferences.

2.Intelligent control and remote monitoring functions:

The system supports remote monitoring of device status, temperature regulation, and power on/off scheduling through mobile applications. This feature not only enhances the overall user experience by providing convenient access to system controls, but also improves management efficiency. Users can monitor and adjust the system's operation from anywhere to ensure optimal performance and energy efficiency.

3.Silent design:

Using low-noise compressors and axial fans, combined with multiple noise reduction control system designs and sound-absorbing barrier technology, to reduce operating noise and provide a peaceful usage environment

>> Technical Parameters

Type	FKH-100II/CGW
	Top out wind
Power specifications	380V3N~50Hz

Heating capacity under A1 operating condition(20)	100kW

Heating consumption power under A1 working condition	47.6kW

Heating capacity under A2 working condition(7)	95kW

Heating consumption power under A2 working condition	50kW

Heating capacity under A3 working cond ition (-12)	90kW

Heating consumption power under A3 working condition	56.5kW

Heating capacity under A4working condition(-20)	80kW

Heating consumption power under A4 working condition	55.2kW

Maximum operating current	160A

Discharge	17.2m³/h

Noise	≤68dB(A)

Water side pressure loss	≤85kPa

Unit size (ength x width x height mm)	2260×1230×2170

CONNECT SIZE	DN65(flange)

Unit weight (kg)	1110

>> Product Uses

1.Shipbuilding industry:

In ship structure operations, the use of specific technologies for welding, cleaning, and drying can improve production efficiency, ensure product quality, and reduce energy consumption.

2.Ink and Coatings Industry:

Used for melting, mixing, and processing materials, as well as drying products, to improve the quality and durability of paints and coatings, and reduce energy consumption.

3.Fertilizer and pesticide manufacturing:

Heating and drying are indispensable in the production process of fertilizers and pesticides, and their application can improve production speed and optimize product quality.

>> Product Operate Guide

Upon taking delivery of the goods, the purchaser will furnish an instructional video.

>> FAQ

Q1.What should I do if the heat pump produces loud noise during operation?

Regularly check the equipment status and replace aging components such as compressors and fans in a timely manner. Ensure stable installation of equipment and reduce vibration and noise generation.

Q2.What should be done if the heating efficiency decreases in a low-temperature environment?

Choose a two-stage compression or cascade heat pump (such as the COLDNOT model) to ensure stable operation at -35 ° C; Install auxiliary electric heating, but pay attention to the increase in energy consumption.

Q3.What if you don't know how to use a heat pump?

Provide detailed user manuals and maintenance guidelines to guide users in the correct use and maintenance of the heat pump; Regularly conduct user training and technical support activities to enhance users' usage skills and maintenance awareness.
