Leomon
| Availability: | |
|---|---|
| Quantity: | |
This 9kW heat pump system, featuring a sleek anthracite (dark grey) exterior, is capable of delivering water at temperatures up to 75°C, making it an ideal choice for efficient heating. The standalone unit comes complete with a remote control, user manual, and water pump, ensuring easy installation and operation. It offers digital temperature control and high energy efficiency, backed by a 10-year manufacturer’s warranty—delivering a reliable, eco-friendly, and energy-saving heating solution.
The unit provides over 6kW of heating capacity at an outdoor temperature of +2°C, and maintains an output of over 9kW even at -7°C. It is perfectly suited for typical two-bedroom semi-detached homes or new-build properties with a floor area of up to 140 square meters. Please share your project details with us so we can perform precise sizing calculations and provide professional recommendations tailored to your needs.
Features
1. With its stylish black finish and adjustable touchscreen control panel, this system combines aesthetic appeal with practical heating functionality.
2. The system operates with exceptional quietness and efficiency, while meeting the high-temperature heating requirements of specific building types.
3. Models utilizing R32 refrigerant are also available; these are optimized for lower-temperature operating conditions and are offered at a more competitive price point.
Advantages
1. Excellent Performance Across Various Conditions
This heat pump system efficiently provides space heating, cooling, and domestic hot water, even in extremely cold climates. It is suitable for use throughout most of Europe.
2. High-Quality Compressor
Equipped with a Panasonic compressor, the system ensures reliable operation, helping you maintain a comfortable home environment.
3. EVI (Enhanced Vapor Injection) Technology
Thanks to EVI technology, the system maintains outstanding heating performance in low-temperature environments. It can deliver 75°C hot water even when the outdoor temperature drops to -15°C, and remains operational in extreme cold—down to as low as -30°C.
4. Multi-Layer Anti-Freeze Protection
Utilizing multiple anti-freeze technologies—including water pump circulation, system circulation, and chassis heating—the system automatically monitors the temperatures of the main unit and the piping. When the ambient temperature drops below 2°C and the water temperature falls below 7°C, the heat pump automatically initiates heating to reach 15°C, effectively preventing the system from freezing.
5. Intelligent Defrosting
By using multiple sensors to monitor operating temperatures in real time, the system performs intelligent defrosting based on actual requirements, avoiding unnecessary operation. Compared to scheduled (timed) defrosting, this method is more efficient and energy-saving.
Type | FKH-12I/GW | FKH-20II/GW | FKH-40II/GW |
Side air outlet | Top out wind | Top out wind | |
Power specifications | 220V～50Hz | 380V 3N～50Hz | 380V 3N～50Hz |
Heating capacity under A1 | 12kW | 20kW | 40kW |
Heating consumption power under | 4.8kW | 8.2kW | 16.2kW |
Heating capacity under A2 | 11.5kW | 19kW | 38kW |
Heating consumption power under | 5.3kW | 8.7kW | 17.5kW |
Heating capacity under A3 |
| 17kW | 35kW |
Heating consumption power |
| 8.5kW | 19kW |
Heating capacity under A4working |
| 15kW | 30kW |
Heating consumption power |
| 9.3kW | 18.5kW |
Maximum operating current | 40A | 35A | 70A |
discharge | 2.1m³/h | 3.5m³/h | 6.9m³/h |
noise | ≤56dB(A) | ≤58dB(A) | ≤60dB(A) |
Water side pressure loss | ≤72kPa | ≤75kPa | ≤75kPa |
Unit size(length x width x height mm) | 1030×410×1390 | 860×780×1780 | 1550×780×1780 |
CONNECT SIZE | DN32(hexagon nipples ) | DN32(hexagon | DN40(hexagon |
Unit weight(kg) | 160 | 212 | 412 |
Please contact us for more information about our heat pumps. Our heat pump experts are ready to answer all your questions and provide a free quote.
