FKH-90II/TGW
LEOMON
| Quantity: | |
|---|---|
The LEOMON FKH-90II/TGW is a high-output industrial steam heat pump delivering 160kg/h of 150°C saturated steam. With a heating capacity of 90kW and power draw of 56kW, this unit is designed for large-scale continuous process heating. Its enlarged evaporator and dual-fan design ensure efficient heat absorption even at low ambient temperatures. Dimensions: 3260×1230×2400 mm, weight 1430 kg. Steam connection DN40, water inlet DN20. Maximum operating current 150A. Noise ≤80 dB(A). Built for long-term reliability, this model serves as a direct replacement for medium-sized electric or fossil-fuel boilers, cutting energy costs and emissions.
1. High Output Meets Demanding Processes
160kg/h of 150°C steam supports heavy-duty applications like large autoclaves, continuous drying lines, and multiple process stations simultaneously. The unit maintains stable pressure and temperature regardless of load variations within its capacity.
2. Superior Energy Efficiency
The FKH-90II/TGW reduces electrical consumption by approximately 38% compared to an electric boiler. When replacing gas or oil boilers with electric drive (via grid power), the operating cost savings are even greater if electricity prices are competitive. Additionally, the unit recovers heat from ambient air, making it a renewable-based solution.
3. Advanced Defrosting for Low-Temperature Performance
The intelligent defrost cycle uses temperature and time criteria to minimize frosting on the evaporator. Defrosting occurs only when necessary, reducing energy loss and maintaining high output even at 15°C ambient.
4. Built-in Redundancy & Safety
Dual refrigeration circuits (in larger models like this) ensure that if one circuit fails, the other can operate at reduced capacity, preventing a complete shutdown. Multiple protection devices safeguard the compressor and electrical components.
