Leomon offers a comprehensive range of commercial heat pumps for school hot water systems, with capacities spanning from 3 HP to 30 HP and power inputs from 2.8 kW to 26 kW, allowing you to select the model best suited to your school’s needs.
As schools are non-profit institutions, minimizing operational and maintenance costs is a priority. An air source heat pump hot water system is an ideal solution for schools.
Heat pump hot water systems represent a new generation of high-tech, eco-friendly, and energy-efficient equipment. Compared to coal, oil, or electric boilers, heat pumps can reduce energy consumption by over 75%. They offer stable operation, a low failure rate, and a long service life—all while remaining unaffected by weather conditions or the changing seasons.
Applications for Commercial Heat Pumps
* Hotels
* Swimming pools
* Hospitals
* Youth hostels
* Restaurants
* Schools
Key Features
1. Continuous Hot Water Supply
Heat pumps provide a consistent supply of hot water regardless of whether it is cloudy, snowing, or nighttime; they do not require direct sunlight.
2. Enhanced Safety
Our heat pumps are designed in accordance with European standards, ensuring both high safety levels and excellent thermal conductivity.
3. Cost-Effective
Compared to combustion-based systems, heat pumps are far more cost-effective. Higher system efficiency translates into significant long-term energy savings.
4. Intelligent Digital Controller
An intelligent digital controller allows for precise regulation of hot water temperature and operating schedules.
5. 75% Reduction in Energy Consumption
Heat pumps are highly efficient because they work by transferring heat rather than generating it. They deliver more energy than they consume, resulting in substantial cost savings.
6. Versatile Applications
Heat pumps serve as an ideal heating and hot water solution for a wide range of settings—from residential homes to swimming pools, and from domestic to commercial environments.
Model | KFXRS-42II | KFXRS-56II | KFXRS-80II | KFXRS-90II | KFXRS-170II | KFXRS-180II |
Heating capacity at ambient temperature | 42.5kW | 56kW | 80kW | 90kW | 170kW | 180kW |
Normal temperature input power | 9.2kW | 12kW | 18kW | 19.5kW | 38kW | 39kW |
Rated voltage | 380V 3N-50Hz | 380V 3N-50Hz | 380V 3N-50Hz | 380V 3N-50Hz | 380V 3N-50Hz | 380V 3N-50Hz |
Heating capacity at low ambient temperatures | 34.5kW | 45kW | 64kW | 73kW | 138kW | 146kW |
Low-temperature input power | 9.1kW | 11.5kW | 17.5kW | 19kW | 37.8kW | 38.5kW |
Maximum input power | 16kW | 21.3kW | 35kW | 40kW | 65kW | 80kW |
Maximum current | 24.5A | 30A | 50A | 88A | 90A | 176A |
Noise | ≤62dB(A) | ≤62dB(A) | ≤70dB(A) | ≤73dB(A) | ≤68dB(A) | ≤80dB(A) |
Electrical protection class | I | I | I | I | I | I |
Waterproof Rating | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 |
Inlet/Outlet Diameter | Male-threaded DN40 | Male-threaded DN40 | Male-threaded DN50 | Male-threaded DN50 | Male-threaded DN65 | Male-threaded DN65 |
External dimensions | 1550*780*1700mm | 1550*780*1750mm | 2205*1030*2170mm | 2205*1030*2170mm | 2260*1550*1840mm | 2206*2020*2170mm |
Unit weight | 400kg | 400kg | 700kg | 750kg | 1050kg | 1200kg |
Our extensive range of heat pump products is designed to meet the hot water requirements of your facility. Please contact us for more information and a free quote.
